NMR100
  • Self contained, wall mount unit
  • RS485 and RS232 interfaces
  • Up to 127 readers with no repeaters
  • 64K Bytes for user list
  • 64K Bytes for event history
  • Memory is battery backed
  • Track 1&2 or 2&3 versions available
  • Visual indicators and LCD display
  • Swipes can be timestamped
  • Emulates IBC STA, J readers
  • Supports up to 100 schedules
Description - Specifications
The NMR series of card readers provides full RS485 networking capability, allowing up to 127 access points, all individually addressable by a single computer. They perform card verification against a list of qualified cards, and up to 100 schedules to activate a relay output which can be used to control a door strike, turnstile or similar. Transactions can be performed locally, stored in the event history and downloaded to the computer at a later time. The NMR100 is fully programmable and can emulate an IBC STA or J type reader. These readers are ideal for door access, labour tracking, etc.
